Difference between VLSI Verification and VLSI Testing?

Difference between VLSI verification and VLSI testing

VLSI verification and VLSI testing are two distinct processes in the field of electronic design automation (EDA) for integrated circuits. While they both aim to ensure the correctness and functionality of VLSI designs, they have different objectives and methodologies. So let’s take a look at the difference between VLSI Verification and VLSI Testing.

VLSI verification focuses on confirming that a design behaves correctly according to its specifications. It involves verifying the functional correctness, performance, and reliability of the integrated circuit (IC) design before it is manufactured. The primary goal of verification is to detect and eliminate design flaws and ensure that the IC functions as intended. Verification engineers use a variety of techniques, such as simulation, formal verification, and emulation, to validate the design against a set of specifications or requirements. Verification involves creating test benches, designing test cases, and running simulations to verify the behavior of the design under various conditions.

VLSI Verification typically involves the following steps:

1. Testbench Creation:

A testbench is a set of stimuli or inputs designed to exercise and thoroughly test the functionality of the VLSI design. Verification engineers create test benches using specialized languages or tools to simulate the behavior of the design under different conditions. The testbench includes stimuli that cover a wide range of scenarios and corner cases to verify the design’s functionality comprehensively.

2. Functional Verification:

The design is simulated using the testbench to observe its behavior and verify that it meets the functional requirements. Simulation tools are used to apply the testbench stimuli to the design and observe the outputs. The observed outputs are compared against the expected results to check for any discrepancies or errors.

Also read: SystemVerilog Testbench/Verification Environment Architecture

3. Coverage Analysis:

Coverage analysis measures the completeness of the testing process by tracking the percentage of code or design features exercised by the testbench. Coverage metrics, such as statement coverage, branch coverage, or toggle coverage, are used to assess the effectiveness of the verification process. Increasing coverage helps ensure that all parts of the design have been adequately tested.

4. Formal Verification:

In addition to simulation-based techniques, formal verification is employed to rigorously analyze and prove the correctness of the design. Formal methods use mathematical techniques to exhaustively analyze the design’s behavior and verify its adherence to specifications. Formal verification complements simulation-based techniques and can help detect subtle design errors or corner-case scenarios that may not be easily identified through simulation alone.

5. Performance Verification:

In some cases, performance verification is conducted to ensure that the design meets the desired performance criteria. Performance metrics, such as timing constraints, power consumption, or signal integrity, are analyzed and validated to ensure the design operates within the specified limits.

The subjects covered in VLSI verification can vary depending on the level of detail and specific focus, but some common topics and subjects that are typically included are Digital Design and VLSI Fundamentals, Verification Methodologies, Hardware Description Languages (HDLs), Testbench Development and Advanced Verification Techniques. If you want to learn more about VLSI verification then check out our ASIC Verification course with key features such as  ASIC Verification Methodologies, Advanced Verilog for Verification, SystemVerilog, UVM, Assertion Based Verification – SVA, Verification Planning and Management, Code and Functional Coverage, Perl scripting language, and VIP coding style.

Also read: SoC Verification Flow and Methodologies

VLSI Testing

VLSI testing, on the other hand, is concerned with ensuring that manufactured integrated circuits meet quality standards and operate correctly under different operating conditions. Testing is performed after the fabrication process to detect manufacturing defects, such as manufacturing variations, process-related faults, or physical defects that may affect the performance or functionality of the IC. Testing involves applying a set of test patterns (input stimuli) to the fabricated IC and comparing the observed outputs against the expected behavior. Various techniques are used in VLSI testing, including automatic test pattern generation (ATPG), built-in self-test (BIST), and boundary scan, to ensure the reliability and functionality of the ICs.

Also read: What is Memory Test & Repair in VLSI?

The goal of VLSI testing is to ensure that the fabricated ICs meet quality standards and operate correctly under various operating conditions.

VLSI testing involves the following key steps:

1. Test Generation:

Test patterns or stimuli are generated to stimulate the inputs of the IC in order to observe its behavior. These patterns are designed to cover a wide range of scenarios and test the functionality of the IC comprehensively. Automatic Test Pattern Generation (ATPG) tools are commonly used to generate test patterns automatically.

2. Test Application:

The generated test patterns are applied to the inputs of the IC, and the resulting outputs are observed. The IC is typically placed in a test environment or test setup, which may include specialized test equipment like testers, probe cards, and test sockets. The test patterns may be applied serially or in parallel, depending on the testing methodology and the characteristics of the IC.

Also read: Verification IP Vs Testbench

3. Fault Detection:

The observed outputs are compared against the expected behavior or the golden model of the IC. Any discrepancies or deviations between the observed and expected outputs indicate the presence of faults or defects in the IC. Faults may include manufacturing variations, process-related defects, physical defects, or other issues that affect the performance or functionality of the IC.

4. Diagnosis and Debugging:

If faults are detected, the next step involves identifying the specific location and nature of the faults within the IC. Various diagnosis techniques, such as scan-based diagnosis, fault simulation, or logic analysis, are employed to pinpoint the faults. Once the faults are diagnosed, designers or engineers can analyze the root causes and make necessary adjustments or corrections to improve the IC’s performance or yield.

5. Yield Analysis:

The results obtained from testing multiple ICs are analyzed to determine the overall yield, which is a measure of the percentage of functional ICs out of the total manufactured. Yield analysis helps identify any systematic issues or patterns in the manufacturing process that may affect the quality or reliability of the ICs.

The subjects covered in VLSI testing include Test Fundamentals, Test Generation Techniques, Test Compression, Test Time Reduction and  Design for Testability (DFT). DFT methodology offers various techniques to increase the efficiency of the silicon testing process of a fabricated chip. If you’re interested in learning more about DFT,  Maven Silicon’s DFT Training course will cover the necessary basics of silicon testing, the importance of testing, and different DFT techniques such as SCAN Insertion, ATPG, JTAG, and BIST. This course will also give you hands-on experience in the implementation of all DFT techniques using the industry-standard tool Tessent from Mentor Graphics.

Also read: Skills required to become a VLSI engineer?

Conclusion

VLSI verification and VLSI testing are integral processes in electronic design automation. VLSI verification focuses on confirming the correctness of a design before manufacturing, employing techniques like simulation and formal verification. Conversely, VLSI testing comes after fabrication, aiming to ensure quality and functionality under different conditions, using methods like test pattern generation and fault detection. Both processes are essential for reliable integrated circuits, spanning from design validation to post-fabrication quality assurance.
